Refrigerated Counter GN1/1 Depth: 700 mm Housing height: 750 mm 3-door
3-door refrigerated counter for GN1/1, with foamed-in evaporator system, convection refrigeration, electronic control, hygienic design.
Temperature: | -2°C / +10°C |
Capacity per section: | 11 x GN1/1 |
Accessories: | 3 racks stainless steel (AISI 304) 3 pairs of rails, tip-proof |
Category: ❄︎$$$ Refrigerated Counters
Built-in cooling
Automatic defrosting and evaporation of the defrost water using hot gas, refrigerating unit for ambient temperatures of min +16°C up to +40°C, ready to plug in
Dimensions with wtp: | 1725 x 700 x 800 mm (LxDxH) |
Dimensions without wtp: | 1718 x 675 x 750 mm (LxDxH) |
Connected load: | 400 W / 230 V |
Refrigeration output: | 322 W -15°C evap. temp. |
Refrigerant: | R290 / 80 g |
Energy consumption: | 1,70 kWh/24 h |
Energy class: | A |
Version | Article number | Gross price plus VAT |
---|---|---|
less worktop | KTM 731170 | 5.522 € |
with worktop incl. splashback | KTM 731171 | 5.901 € |
with worktop all sides bent down | KTM 731172 | 5.946 € |
Remote cooling
Ready for connection by customer, automatic defrosting and defrost water run-off
Dimensions with wtp: | 1625 x 700 x 800 mm (LxDxH) |
Dimensions without wtp: | 1618 x 675 x 750 mm (LxDxH) |
Connected load: | 130 W / 230 V |
Refrigeration output: | 322 W -15°C evap. temp. |
Version | Article number | Gross price plus VAT |
---|---|---|
less worktop | KTO 731170 | 5.049 € |
with worktop incl. splashback | KTO 731171 | 5.419 € |
with worktop all sides bent down | KTO 731172 | 5.465 € |
Accessories
(Mehrpreise für Schubladen anstelle von Flügeltüren)
Drawers | Article number | Gross price plus VAT | |
---|---|---|---|
Drawers GN1/1 Useful height: 265 mm | 1/2 | 1/2 | 700084 | 672 € |
Drawers GN1/1 Useful height: 160/160/160 mm | 1/3 | 1/3 | 1/3 | 700085 | 953 € |
Drawers GN1/1 Useful height: 115/429 mm | 1/3 | 2/3 | 700086 | 682 € |
Technical compartment mounted sinistral | 700606 | 295 € | |
Installation compartment mounted sinistral | 700605 | 295 € |
Accessories | Article number | Gross price plus VAT |
---|---|---|
Rack GN1/1, 325 x 530 mm, stainless steel (AISI 304) | 701435 | 41 € |
Pair of rails, tip-proof, stainless steel (AISI 304) | 700550 | 41 € |
