Refrigerated Counter GN1/1 Depth: 700 mm Housing height: 750 mm 3-door
3-door refrigerated counter for GN1/1, with foamed-in evaporator system, convection refrigeration, electronic control, hygienic design.
| Temperature: | -2°C / +10°C |
| Capacity per section: | 11 x GN1/1 |
| Accessories: | 3 racks stainless steel (AISI 304) 3 pairs of rails, tip-proof |
Built-in cooling
Automatic defrosting and evaporation of the defrost water using hot gas, refrigerating unit for ambient temperatures of min +16°C up to +40°C, ready to plug in
| Dimensions with wtp: | 1725 x 700 x 800 mm (LxDxH) |
| Dimensions without wtp: | 1718 x 675 x 750 mm (LxDxH) |
| Connected load: | 400 W / 230 V |
| Refrigeration output: | 322 W -15°C evap. temp. |
| Refrigerant: | R290 / 80 g |
| Energy consumption: | 1,70 kWh/24 h |
| Energy class: | A |
| Version | Article number | Gross price plus VAT |
|---|---|---|
| less worktop | KTM 731170 | 5.688 € |
| with worktop incl. splashback | KTM 731171 | 6.079 € |
| with worktop all sides bent down | KTM 731172 | 6.125 € |
Remote cooling
Ready for connection by customer, automatic defrosting and defrost water run-off
| Dimensions with wtp: | 1625 x 700 x 800 mm (LxDxH) |
| Dimensions without wtp: | 1618 x 675 x 750 mm (LxDxH) |
| Connected load: | 130 W / 230 V |
| Refrigeration output: | 322 W -15°C evap. temp. |
| Version | Article number | Gross price plus VAT |
|---|---|---|
| less worktop | KTO 731170 | 5.201 € |
| with worktop incl. splashback | KTO 731171 | 5.582 € |
| with worktop all sides bent down | KTO 731172 | 5.629 € |
Accessories
(Mehrpreise für Schubladen anstelle von Flügeltüren)
| Drawers | Article number | Gross price plus VAT | |
|---|---|---|---|
| Drawers GN1/1 Useful height: 265 mm | 1/2 | 1/2 | 700084 | 693 € |
| Drawers GN1/1 Useful height: 160/160/160 mm | 1/3 | 1/3 | 1/3 | 700085 | 982 € |
| Drawers GN1/1 Useful height: 115/429 mm | 1/3 | 2/3 | 700086 | 703 € |
| Technical compartment mounted sinistral | 700606 | 304 € | |
| Installation compartment mounted sinistral | 700605 | 304 € |
| Accessories | Article number | Gross price plus VAT |
|---|---|---|
| Rack GN1/1, 325 x 530 mm, stainless steel (AISI 304) | 701435 | 43 € |
| Pair of rails, tip-proof, stainless steel (AISI 304) | 700550 | 43 € |
