Freezing Counter GN1/1 Depth: 700 mm Housing height: 430 mm 2-door
2-door refrigerated counter for GN1/1, with foamed-in evaporator system, convection refrigeration, electronic control, hygienic design.
| Temperature: | -18°C / -20°C |
| Capacity per section: | 6 x GN1/1 |
| Accessories: | 2 racks stainless steel (AISI 304) 2 pairs of rails, tip-proof |
Built-in cooling
Automatic defrosting and evaporation of the defrost water using hot gas, refrigerating unit for ambient temperatures of min +16°C up to +40°C, ready to plug in
| Dimensions with wtp: | 1250 x 700 x 600 mm (LxDxH) |
| Dimensions without wtp: | 1246 x 675 x 580 mm (LxDxH) |
| Connected load: | 400 W / 230 V |
| Refrigeration output: | 200 W -30°C evap. temp. |
| Refrigerant: | R290 / 70 g |
| Energy consumption: | 4,0 kWh/24 h |
| Energy class: | C |
| Version | Article number | Gross Price |
|---|---|---|
| less worktop | TKM 721140 | 5.499 € |
| with worktop (height 20 mm), incl. splashback | TKM 721141 | 5.847 € |
| with worktop (height 20 mm), all sides bent down | TKM 721142 | 5.894 € |
| Refrigerated Counter TKM 721140, but with length of 1200 mm (for adapting to thermal equipment) *C-Models without stainless steel coverage | TKM 721140-C12 | 5.827 € |
| Refrigerated Counter TKM 721142, but with length of 1200 mm (for adapting to thermal equipment) *C-Models with stainless steel coverage, 1.5 mm | TKM 721142-C12 | 6.221 € |
| Refrigerated Counter TKM 721140, but with length of 1400 mm (for adapting to thermal equipment) *C-Models without stainless steel coverage | TKM 721140-C14 | 5.827 € |
| Refrigerated Counter TKM 721142, but with length of 1400 mm (for adapting to thermal equipment) *C-Models with stainless steel coverage, 1.5 mm | TKM 721142-C14 | 6.221 € |
Remote cooling
Ready for connection by customer, automatic defrosting and defrost water run-off
| Dimensions with wtp: | 1150 x 700 x 600 mm (LxDxH) |
| Dimensions without wtp: | 1146 x 675 x 580 mm (LxDxH) |
| Connected load: | 180 W / 230 V |
| Refrigeration output: | 200 W -30°C evap. temp |
| Version | Article number | Gross price plus VAT |
|---|---|---|
| less worktop | TKO 721140 | 4.927 € |
| with worktop (height 20 mm), incl. splashback | TKO 721141 | 5.271 € |
| with worktop (height 20 mm), all sides bent down | TKO 721142 | 5.316 € |
| Refrigerated Counter TKO 721140, but with length of 1200 mm (for adapting to thermal equipment) *C-Models without stainless steel coverage | TKO 721140-C12 | 5.262 € |
| Refrigerated Counter TKO 721142, but with length of 1200 mm (for adapting to thermal equipment) *C-Models with stainless steel coverage, 1.5 mm | TKO 721142-C12 | 5.651 € |
| Refrigerated Counter TKO 721140, but with length of 1400 mm (for adapting to thermal equipment) *C-Models without stainless steel coverage | TKO 721140-C14 | 5.262 € |
| Refrigerated Counter TKO 721142, but with length of 1400 mm (for adapting to thermal equipment) *C-Models with stainless steel coverage, 1.5 mm | TKO 721142-C14 | 5.651 € |
Accessories
(Surcharge for drawers instead of hinged doors)
| Drawers | Article number | Gross price plus VAT | |
|---|---|---|---|
| Drawers GN1/1 Useful height: 250 mm | 1/1 | 700115 | 461 € |
| Accessories | Article number | Gross price plus VAT |
|---|---|---|
| Rack GN1/1, 325 x 530 mm, stainless steel (AISI 304) | 701435 | 43 € |
| Pair of rails, tip-proof, stainless steel (AISI 304) | 700550 | 43 € |
